Hana S and E series Pick Up

Hana E Serie
ab CHF 339.00
Hana M Serie
ab CHF 1 190.00
Hana S Serie
ab CHF 519.00

Die japanische Excel Sound Corporation produziert seit über 50 Jahren MC-Systeme für zahlreiche renommierte Hersteller. Unter der Marke Hana hat sie nun eigene MC-Systeme lanciert, die in jeder Beziehung überzeugen und geradewegs zu den Besten ihrer Preisklasse gehören.


Hana M Serie

As written by Geoff Husband-san in his TNT/France review - “To compare the Hana with a cartridge costing 10x as much seems madness, but “blind”, I would have believed they were in the same class - extraordinary.”



What are the secrets? First, Excel Sound produces all the major parts used in Hana MC cartridges itself, from materials like aluminum for the cantilever, Alnico for the electro-motive power magnet, pure iron for the magnetic circuit and 4N copper wire for MC wiring. The electrical sub-assembly is then packaged in an ABS plastic body. So you see, of the constituent materials are not rare or expensive, but designed and manufactured correctly, they can produce cartridges with a very excellent sound for a reasonable price – a rare end product indeed.

CHF 1 190.00

  • verfügbar
  • 1 - 3 Tage Lieferzeit1

Hana S Serie

Hana SH: High output MC-cartridge, nude Shibata diamond

Hana SL: Low output MC-cartridge, nude Shibata diamond

Retip Hana H Serie: Retip Hana SH/SL



Technische Daten

                                                                           Hana SH                               Hana SL

Stylus

nude Shibata diamond

nude Shibata diamond

Cantilever

Aluminum

Aluminum

Output Level

0.5mV/1kHz

2mV/1kHz

Output Balance

<1.5dB/1kHz

<1.5dB/1kHz

Tracking force

2.0g

2.0g

Trackability

70μm/2.0g

70μm/2.0g

Channel Separation

28dB/1kHz

28dB/1kHz

Frequency Response

15~32000Hz

15~32000Hz

Impedance

130 ohm/1kHz

30 ohm/1kHz

Suggested Load Impedance

47k ohm

>400 ohm

Cartridge Weight

5.0g

5.0g

Body Color

Black



Black





CHF 649.00

  • verfügbar
  • 1 - 3 Tage Lieferzeit1

Hana E Serie

Hana EH: High output MC-cartridge, synthetic elliptical stylus

Hana EL: Low output MC-cartridge, synthetic elliptical stylus

Retip Hana E Type: Retip Hana EH/EL



Technische Daten

                                                                Hana EH                          Hana EL

Stylus

Synthetic elliptical

Synthetic elliptical

Cantilever

Aluminum

Aluminum

Output Level

0.5mV/1kHz

2mV/1kHz

Output Balance

<2dB/1kHz

<2dB/1kHz

Tracking force

2.0g

2.0g

Trackability

70μm/2.0g

70μm/2.0g

Channel Separation

25dB/1kHz

25dB/1kHz

Frequency Response

15~25000Hz

15~25000Hz

Impedance

130 ohm/1kHz

130 ohm/1kHz

Suggested Load Impedance

47k ohm

>400 ohm

Cartridge Weight

5.0g

5.0g

Body Color

Moss Green

Moss Green

CHF 429.00

  • verfügbar
  • 1 - 3 Tage Lieferzeit1
